Site Plan — Raul Medina, Jr., 6305 NW 74 Ave, Miami, FL (1997)

H ZONING INFORMATION ZONING RU-BA 1 B/M LOT AREA 31,884 S.F. ACREAGE 0.732 ACRES BUILDING AREAS: FIRST FLOOR 14,700 S.F. SECOND FLOOR 14,700 S.F. TOTAL 29,400 S.F. SETBACKS REQUIRED PROVIDED FRONT 20' 73' SIDE 15' 35' REAR 20' 10'-0" LANDSC AREA 30,575 S.F. 32,551 S.F. PERCENTAGE 29% 77.2% GREENBELT 0' 25' PARKING 124 120 FLOOR AREA RATIO 45.61 % LOT COVERAGE 22.84 % LEGAL DESCRIPTION: LOT 13 & 12 OF BLOCK 30 J.D. HEAD'S PARTS UNIT 'A' ACCORDING TO THE PLAT THEREOF AS RECORDED IN PLAT BOOK 48 AT PAGE 3 OF THE PUBLIC RECORDS OF DADE COUNTY, FLORIDA, LIKE THE SOUTH 50 FEET THEREOF. ZONING NOTICE: IN ADDITION TO THE REQUIREMENTS OF THIS PERMIT, THERE MAY BE ADDITIONAL RESTRICTIONS APPLICABLE TO THIS PROPERTY THAT MAY BE FOUND IN THE PUBLIC RECORDS OF THIS COUNTY, SECTION 47-608, FLORIDA STATUTES, EFFECTIVE 1/1/87. ELEVATION: GROUND OF ROAD DADE COUNTY FLOOD CRITERIA FEDERAL FLOOD CRITERIA PROPOSED FIN FLOOR AREA ADJACENT TO LAKE OR CANAL TO BE GRADED SO AS TO PREVENT DIRECT OVERLAND DISCHARGE OF STORMWATER INTO LAKE OR CANAL. LOT WILL BE GRADED SO AS TO PREVENT DIRECT OVERLAND DISCHARGE OF STORMWATER ONTO ADJACENT PROPERTY. LOWEST FINISHED FLOOR ELEVATION (INCLUDING BASEMENT) DISTRICT ELEVATION CITY FLOOD CRITERIA GROUND OF ROAD DISTRICTS R.P.L. 69 H OTHER REQUIRED PROPOSED LOWEST FLOOR AS-BUILT ELEVATION SURVEY IS REQUIRED BEFORE MAKING ANY INSPECTION ABOVE LOWEST FLOOR *SHALL BE 0'-0" INCHES ABOVE FINISHED GRADE SITE TO BE FILLED TO COUNTY FLOOD CRITERIA ELEVATION N.A.V.D., OR AN ELEVATION NO LESS THAN THE HIGHEST APPROVED GROUND ELEVATION OF THE ROAD FRONTING THE PROPERTY SOIL TREATMENT: ALL SOIL BELOW STRUCTURE SHALL HAVE PRECONSTRUCTION TREATMENT FOR PROTECTION AGAINST TERMITES. CONTRACTOR SHALL SUBMIT CERTIFICATE OF COMPLIANCE TO VERIFY TREATMENT PARKING STALL DETAIL (FOR THE PHYSICALLY DISABLED) N.T.S. TYP. PARKING STALL DTL. N.T.S. WHEELSTOP DETAIL N.T.S LOCATION PLAN N.T.S S.W. 32nd AVENUE THE NORTH LINE OF THE S.W. 32ND AVE. EXISTING 6' HIGH MASONRY WALL SLOPED PAVEMENT IN SPANISH 'S' TILE ROOF HEIGHT EL. 125'-0" PROPOSED 2 STORY OFFICE BUILDING TOTAL BUILDING AREA 37400 S.F. LOT 13 ZONING EU-H LOT AREA 40,470 S.F. LOT 12 ZONING RU-5A LOT AREA 41,414 S.F. S.W. 42nd STREET (BIRD ROAD) SOUTH LINE OF 'SEC. 14-54-39' SITE PLAN SCALE 1" = 20'-0" LINE OF FORMITE COURSE 6' HIGH 6' HIGH MASONRY WALL LOT 11 ZONING EU-H REVISIONS: DATE: 4-7-91 DRAWN BY: A.R. CHECKED BY: J.M. JOB NO.: 92-01 PROPOSED PROFESSIONAL OFFICE BUILDING FOR: MR. RAUL MEDINA JR. 6305 NW 74 AVE MIAMI, FL 33166 CARRERA RAMOS ARCHITECTS, INC. 3625 NW 82 AVENUE MIAMI, FLORIDA 33166 (305) 593-0770 FAX (305) 593-8642 AA 0001421 MIGUEL A. CARRERA, JR., A.A. Lic. No. 96121 PABLO E. RAMOS-GOMEZ, A.A. Lic. No. 96120 SHEET NO. A-1 OF

Diane O'Quinn-Williams Supervisor September 23, 1997 2. Each building should have address numbers conspicuously mounted which are not less than three inches in height and easily observable from the roadway. Landscaping and lighting should be maintained so that the numbers are never allowed to become obscured. 3. Shrubbery and landscaping at all driveways and intersections should be sufficiently set back and kept trimmed to permit vehicle operators an unobstructed view of other traffic and pedestrians. 4. Stairwells should have access controlled to restrict movements of persons contemplating criminal activity. 5. Adequate lighting, closed circuit television, and security officers in vehicle parking areas can discourage criminal activity. 6. Designation of areas within the development to be kept free of parked motor vehicles in order to facilitate access to buildings by emergency vehicles (fire lanes) is accomplished by application of the owner or lessor of the development pursuant to Dade County Ordinance 30-388, Creation of Emergency Vehicle Zones. Only those developments with zones so designated are authorized to have police enforcement. 7. The U.S. Department of Housing and Urban Development recommends five to ten foot-candles of light for heavily used spaces; e.g., paths, entries, and parking areas. Outdoor lighting can be one of the most effective deterrents against crime. Properly used, it discourages criminal activity and reduces fear. 8. Any unmanned, card accessible, security entrance gate should have a coded lock-box feature for emergency access by police and fire-rescue vehicles. 9. Additional Comments: Police services are currently provided by our Doral Station (Police District 3) located at 9101 NW 25 Street. During the month of June 1997, based upon a districtwide statistical analysis, the average emergency response time was 4.0 minutes. Station personnel handled 6,047 calls for police service and operated with 198 sworn officers, to deliver service to an area of 284.5 square miles with a population of 166,525. Please forward any future applications/site plans regarding the aforementioned property for further impact considerations. If you need additional information, please contact Officer Patricia Addison at [illegible]. JF/pa 13

CANOPY TREE PLANTING DTL. N.T.S. BLACK GARDEN HOSE SUFFICIENT DOUBLE GEIGER TO ALLOW 6" TO 8" PER TREE YELLOW FLAGGING TAPE SURVEYOR'S TAPE REMOVE EXCESS SOIL FROM TOP OF BALL FERTILIZER TABLETS COMPACTED SUBGRADE LANDSCAPING NOTES AND STANDARDS 1. ALL LANDSCAPE INSTALLATION SHALL MEET THE APPROVED SPECIFICATIONS OF THE PLANTING AND IRRIGATION PLAN AS PREPARED BY LANDSCAPE ARCHITECTURE. 2. LANDSCAPE CONTRACTOR SHALL PROVIDE A COMPLETE IRRIGATION SYSTEM AND ENSURE IRRIGATION PLANT DETAILS AND SPEC AS REQUIRED. REFER TO IRRIGATION PLAN FOR IRRIGATION DETAILS. 3. LANDSCAPE CONTRACTOR SHALL VERIFY LOCATION OF ALL EXISTING UTILITIES AND CONSTRUCT HIS PLAN TO AVOID THEM. ANY SITE PLANTING SHALL BE CONSTRUCTED IN ACCORDANCE WITH LANDSCAPE CONTRACTOR SHALL VERIFY THE EXISTENCE OF ANY UNDERGROUND UTILITIES PRIOR TO EXCAVATION OF TRENCHES. LANDSCAPE CONTRACTOR SHALL BE RESPONSIBLE FOR ANY DAMAGE TO EXISTING UTILITIES DUE TO NEGLIGENCE OF HIS WORKMEN. 4. ALL LAW AREAS ARE MARKED AS TOPE SHALL BE SOLIDLY COMPACTED WITH 4" OF COMPACTED SUBGRADE SOIL. ALL SOIL TO BE 6" BELOW FINAL GRADE AND 6" FROM ALONG PLANTED AREAS. 5. PLANTING SOIL TROUGHS FOR EXISTING TREES AND SHRUBS ON CURBS OR SIDEWALKS SHALL BE VACUUMED FOR A MINIMUM WIDTH OF 36" IN ALL DIRECTIONS FROM THE TRUNK. THE SOIL IN THE TROUGHS SHALL BE COMPACTED TO NATURAL DENSITY. PLANTING SOIL SHOULD NOT BE COMPACTED. AN ADDITIONAL 6" OF TOPSOIL MAY BE ADDED TO THE TROUGHS TO PROVIDE THE SOIL TO THE EXISTING, REMAINING AREAS OF EXISTING PLANT MATERIAL. 6. ALL PLANTING AREAS SHALL RECEIVE A TOPSOIL OF 6" OF NATURAL ORGANIC MATERIAL. TOPSOIL SHALL COMPLY WITH IMPORTANT TO MAINTAIN SOIL MOISTURE AND PREVENT EROSION. 7. ALL TREES AND PALMS IN THE LAW AREAS ARE TO RECEIVE A 6" DIAMETER MULCH RADIUS AT THE BASE OF THE TRUNK. SOIL EXCAVATION BLDG. GREEN LAND (SEE LEGEND) HOT LAND (SEE LEGEND) LANDSCAPE OPEN SPACE STRENGTH LENGTH LAWN AREA TREE PLANTING IN CROWNED TREES PER NET LOT TOTAL # OF PLANTED TREES TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TREES PER NET LOT TOTAL # OF PLANTED TRE...... PALM TREE PLANTING DTL. N.T.S. THE PALM PROVEN GROWING TRANSPARENCY DO NOT USE PROVEN GROWING AND TREE B/H GRADE 4 LAYERS OF BURLAP TOP AND BOTTOM STEEL BANDING 5 (TYPICAL) BATTENS RIB NAIL, TYPICAL BATTEN TO BATTEN 6" MULCH LAYER (4) TYP. PRESSURE TREATED WOOD BRANCHES FERTILIZER TABLETS COMPACTED SUBGRADE SOIL MIX PLANTING SCHEDULE TYPE COMMON NAME BOTANICAL NAME SPECIFICATION QUANTITY NOTES L1001 LIVORPE LIVORPE MACROCARPA 1 GAL. PAIL 100 NO L1002 EXORA EXORA SP. 3 GAL. PAIL 100 NO L1003 PETAS PETASUS LANCEOLATA 3 GAL. PAIL 100 NO L1004 RED-TIP COCOPLUM CHRYSOBALANUS ICACO 3 GAL. PAIL 100 YES L1005 KATIPAS GRASS CORTADERIA BELLONA 3 GAL. PAIL 100 YES L1006 SABAL PALMETTO CABAESE PALM 10' OVERALL HEIGHT 100 YES L1007 ROYAL PALM ROystonea ELATA 10' OVERALL HEIGHT 100 YES L1008 HIBISCUS HIBISCUS MANIHOT 10' OVERALL HEIGHT 100 YES L1009 LIVE OAK QUERCUS VIRGINIANA 10' OVERALL HEIGHT 100 YES PROPOSED PROFESSIONAL OFFICE BUILDING FOR MR RAUL MEDINA, JR. 6800 NW 74 AVE MIAMI, FL. 33166-4000 REVISIONS: DATE: DRAWN BY: CHECKED BY: JOB NO.: CABRERA RAMOS ARCHITECTS, P.A. 3828 N.W. 82 AVENUE SUITE 314 MIAMI, FLORIDA 33166 (305) 593-0790 FAX (305) 593-0992 AA 0001821 S.W. 42nd STREET (BIRD ROAD) LANDSCAPING PLAN SCALE 1" = 20'-0" SHRUB PLANTING DTL. N.T.S. 6" MULCH LAYER COMPACTED SUBGRADE SOIL MIX FERTILIZER TABLETS COMPACTED SOIL MIX SHEET NO. L-1 OF

REVISIONS: DATE: 4-15-91 DRAWN BY: RRS CHECKED BY: JMC JOB NO.: 92-47 PROPOSED PROFESSIONAL OFFICE BUILDING FOR: MR. RAUL MEDINA, Jr. MIAMI, FL 33146 898-4020 CAMPERA RAMOS ARCHITECTS, INC. 3625 N.W. 82 AVENUE SUITE 316 MIAMI, FLORIDA 33166 (305) 593-0790 FAX (305) 390-8062 AA C001621 SHEET NO. A-4 OF SPANISH TILE PARAPET MAX. TOP OF PARAPET EL. 127'-0" SPANISH TILE PARAPET MAX. TOP OF PARAPET EL. 127'-0" TOP OF ROOF EL. 120'-0" SECOND FLOOR EL. 10'-0" FIRST FLOOR EL. 0'-0" SMOOTH STUCCO FINISH KEYSTONE FINISH MOLDING TINTED FIXED GLASS IN WHITE MULLION SMOOTH STUCCO FINISH KEYSTONE FINISH MOLDING TINTED FIXED GLASS IN WHITE MULLION CHARACTER STUDY SCALE: 1/8" = 1'-0"

CABRERA RAMOS ARCHITECTS, INC. PROFESSIONAL PREPARER'S STATEMENT OF LANDSCAPING COMPLIANCE PROCESS NUMBER Legal description: Lot 1245 Block 13, Subdivision JG HEAD'S FARMS UNIT A P.B. 46, Page 17, Development name MR. RAUL MEDINA. Located at (address) NORTH EAST CENTER OF BIELO ROAD & 1012 NO AVE. I/We hereby certify that the landscaping/irrigation plan being submitted for the above captioned complies with the requirements of Ordinance 95-222 (landscape ordinance) as to species, height, trunk width and location at time of planting, and that the species as shown are in accordance with the accepted species approved by Dade County and that none of the species are from the prohibited list. Additionally automatic sprinkler systems (if applicable) comply with requirement of said ordinance as to type of heads, spray system, location, etc. I/We further certify that I/we am/are authorized under Chapter 481, Florida statutes to prepare and submit this landscaping/irrigation plan. Professional Preparer's Signature Print Name MILVER A CABRERA Seal: STATE OF FLORIDA COUNTY OF DADE The foregoing instrument was acknowledged before me this 7 day of APRIL, 1997, by MILVER A CABRERA, of CABRERA RAMOS ARCHITECTS, INC. a FLORIDA corporation, on behalf of the corporation. He/She is personally known to me or has produced , as identification and did/did not take an oath. Witness my signature and official seal this 7 day of APRIL, 1997, in the County and State aforesaid, the date and year last aforesaid. Notary Public Print Name Ana M. Garcia My Commission Expires ANA MA GARCIA Comm. No. CC 564598 My Comm. Exp. Oct. 10, 2000 Bonded thru Pichard Ins. Agcy. DORAL EXECUTIVE OFFICE PARK 8201 N.W. 32ND AVENUE SUITE 304 MIAMI, FLORIDA 33166 / (305) 593-0750 FAX (305) 593-8862

[illegible]
