Architectural Drawing — Raul Medina Jr., Proposed Professional Office Building (1991-2001)

ZONING INFORMATION ZONING RU-SA & BH-M LOT AREA 21,644 SF ACREAGE +/-0.50 ACRES BUILDING AREAS: FIRST FLOOR 16,700 SF SECOND FLOOR 8,700 SF TOTAL 25,400 SF SETBACKS REQUIRED PROVIDED FRONT 20' 11' SIDE 10' 10' REAR 10' 10' LANDSCAPE AREA 2041.1 SF 2258 SF PERCENTAGE 20% 21.2% GREENBELT 8' 20' + PARKING 124 125 FLOOR AREA RATIO 45.61 % LOT COVERAGE 22.04 % LEGAL DESCRIPTION LOT 12 & 13 OF BLOCK 3 US HEADS PARKS UNIT 'A' ACCORDING TO THE PLAT THEREOF AS RECORDED IN PLAT BOOK 46 AT PAGE 18 OF THE PUBLIC RECORDS OF DADE COUNTY, FLORIDA LESS THE SOUTH 50 FEET THEREOF. ZONING NOTICE IN ADDITION TO THE REQUIREMENTS OF THIS PERMIT, THERE MAY BE ADDITIONAL RESTRICTIONS APPLICABLE TO THIS PROPERTY THAT MAY BE FOUND IN PUBLIC RECORDS OF THIS COUNTY, SECTION 410.008, FLORIDA STATUTES, EFFECTIVE 10/01/87. ELEVATION: CROWN OF ROAD DADE COUNTY FLOOD CRITERIA FEDERAL FLOOD CRITERIA PROPOSED FIN FLOOR AREA ADJACENT TO LAKE OR CANAL TO BE GRADED SO AS TO PREVENT DIRECT OVERLAND DISCHARGE OF STORMWATER INTO LAKE OR CANAL. LOT WILL BE GRADED SO AS TO PREVENT DIRECT OVERLAND DISCHARGE OF STORMWATER ONTO ADJACENT PROPERTY. LOWEST FINISHED FLOOR ELEVATION (INCLUDING PAVEMENT) ELEVATION DISTRICT ELEVATION CITY FLOOD CRITERIA CROWN OF ROAD DISTRICTS H.F.H. G.F.H. OTHER REQUIRED PROPOSED LOWEST FLOOR AS-BUILT ELEVATION SURVEY IS REQUIRED BEFORE MAKING ANY INSPECTION ABOVE LOWEST FLOOR. SHALL BE 4" INCHES ABOVE FINISHED GRADE SITE IS GRADED TO COUNTY FLOOD CRITERIA ELEVATION 6'0", OR AN ELEVATION NOT LESS THAN THE HIGHEST APPROVED CROWN ELEVATION OF THE ROAD FRONTING THE PROPERTY. SOIL TREATMENT: ALL SOIL BELOW STRUCTURE SHALL HAVE PRECONSTRUCTION TREATMENT FOR PROTECTION AGAINST TERMITES. CONTRACTOR SHALL SUBMIT CERTIFICATE OF COMPLIANCE TO VERIFY TREATMENT. PARKING STALL DETAIL (FOR THE PHYSICALLY DISABLED) N.T.S. 12" 8' 12" 12" 8' 12" SYMBOL ON BLUE BLUE ON WHITE 12'-0" 8'-0" 12'-0" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/...... 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 1/......

REVISIONS: DATE: 9-3-91 DRAWN BY: AMHS CHECKED BY: RSB JOB NO.: 452-91 PROPOSED PROFESSIONAL OFFICE BUILDING FOR: MR. RAUL MEDINA JR. 6903 NW 74 AVE MIAMI, FL 33166-4600 CABRERA RAMOS ARCHITECTS, INC. 3625 N.W. 87 AVENUE SUITE 316 MIAMI, FLORIDA 33166 (305) 593-0760 FAX (305) 593-8862 AA 0301921 MIGUEL A. CABRERA, JR., P.E. State Reg. No. AR3118 ROSE E. GONZALEZ-BOTTO, P.E. State Reg. No. AR10308 SHEET NO. A-2 OF 1 2 3 4 5 6 7 8 72'-2" 45'-1" 49'-7" 22'-4" 22-1/2" 21'-0" 27'-0" 21'-0" 22-10" 22'-4" A B C D E 145'-0" 11'-0" 30'-0" 35'-0" 145'-0" 17'-0" 30'-0" 30'-0" 30'-0" REAR ENTRANCE STAIR #2 ELEC. MACHINE OFFICE AREA CORRIDOR OFFICE AREA JAN. ROOM W.C. M.C. ELEC. ROOM STAIR #1 CORRIDOR OFFICE AREA ELEC. ROOM LOBBY ENTRY OFFICE AREA CORRIDOR ELEC. MACHINE STAIR #1 LOBBY PORTE COCHERE GROUND FLOOR SCALE: 3/32" = 1'-0"

REVISIONS: DATE: 4-13-97 DRAWN BY: AMHS CHECKED BY: RRD JOB NO.: 432-97 PROPOSED PROFESSIONAL OFFICE BUILDING FOR: MR RAUL MEDINA JR. 6605 NW 74 AVE MIAMI, FL 888-4100 CABRERA RAMOS ARCHITECTS, INC. 3605 N.W. 82 AVENUE SUITE 310 MIAMI, FLORIDA 33166 (305) 893-0750 FAX (305) 893-9662 AA C001921 MIGUEL A. CABRERA, JR. AIA State Reg. No. AR13119 ROGER E. DAVIES-BOTTA, A.A. State Reg. No. AR15309 COPYRIGHT 1997 CABRERA RAMOS, INC. THIS DRAWING IS THE PROPERTY OF CABRERA RAMOS, INC. AND SHALL NOT BE REPRODUCED WITHOUT WRITTEN PERM. SHEET NO. A-3 OF 1 2 3 4 5 6 7 8 172'-2" 45'-1" 81'-0" 22'-4" 22'-10" 27'-0" 27'-0" 21'-0" 22'-4" 45'-1" 22'-4" A 70'-0" B 70'-0" C 60'-0" D 31'-0" E 31'-0" OFFICE AREA CORRIDOR STAIR 4B JAN ROOM WATER COOLER ELEC ROOM LOBBY BELOW CORRIDOR LOBBY PORTE COCHERE BELOW STAIR 1B ELEC ELEM OFFICE AREA SECOND FLOOR SCALE: 3/32" = 1'-0"

REVISIONS: DATE: 9-17-97 DRAWN BY: RRS CHECKED BY: MAC JOB NO.: 482-41 PROPOSED PROFESSIONAL OFFICE BUILDING FOR: MR. RAUL MEDINA Jr. 2625 NW 74 AVE MIAMI, FL 556-4000 CABRERA RAMOS ARCHITECTS, INC. 2625 N.W. 82 AVENUE SUITE 316 MIAMI, FLORIDA 33155 (305) 593-9750 FAX (305) 593-9952 AA C001821 MIGUEL A. CABRERA, JR., R.A. State Reg. No. AR-5115 ROSA D. RAMOS-RAMOS, R.A. State Reg. No. AR-16293 SHEET NO. A-4 OF SPANISH TILE PARAPET 6 12 MAX. TOP OF PARAPET 4 EL. 42'-0" SPANISH TILE PARAPET 6 12 MAX. TOP OF PARAPET EL. 42'-0" TOP OF ROOF EL. 42'-0" SECOND FLOOR EL. 17'-0" FIRST FLOOR EL. 0'-0" SMOOTH STUCCO FINISH KEYSTONE FINISH MOLDING TINTED FIXED GLASS IN WHITE MULLIONS SMOOTH STUCCO FINISH KEYSTONE FINISH MOLDING TINTED FIXED GLASS IN WHITE MULLIONS CHARACTER STUDY SCALE: 1/8" = 1'-0".

BLACK GARDEN HOSE TWISTED DOUBLE STRAND 2 GAL. GALLY WIRE CUT 3 PER TREE YELLOW FLAGGING TAPE TURNBUCKLE REMOVE BURLAP FROM TOP 1/2 OF BALL 3"X4"X4" PRESSURE TREATED WOOD STAKES PERLITE TABLETS COMPACTED SUBGRADE SOIL MIX EXISTING GRADE 4" WATER BASIN 3" MULCH LAYER CLEAR TO GRADE 12" DEPTH MIN. ROOT BALL CANOPY TREE PLANTING DTL. N.T.S. LANDSCAPING NOTES AND STANDARDS 1. ALL LANDSCAPING MATERIALS SHALL MEET THE APPLICABLE REQUIREMENTS OF ANY STANDARDS FOR FORESTRY, STOCKS, SPECIES, PLANTATION, AND GROWTH ACTIVITY IN DAILY HORTICULTURE, CORNELL UNIVERSITY, LATEST ED. 2. LANDSCAPE CONTRACTOR SHALL BE RESPONSIBLE FOR IRRIGATION SYSTEM AND SEEDY PREPARATION. PLANT DETAILS AND SPEC AS REQUIRED. REFER TO IRRIGATION PLAN FOR IRRIGATION SPECS. 3. LANDSCAPE CONTRACTOR SHALL VERIFY LOCATION OF ALL UNDERGROUND AND OVERHEAD UTILITIES TO AVOID COMPLICATED PLANTING. PRIOR TO CERTIFICATION OF WORK. LANDSCAPE CONTRACTOR SHALL CONTACT THE NECESSARY UTILITY COMPANIES PRIOR TO CONTINUING WORK OR SIGNING LANDSCAPE CERTIFICATE. CONTRACTOR MAY NOT CONTINUE WORK OR COMPLETE OR DISCREPANCIES PRIOR TO BEGINNING OF WORK. 4. AT AUGMENT, AL PREPARED SOIL FOR ALL TREES TO ACCOMPANY WITH 10% GIL TREAT AND CUT DOWN PLANTED WORK TO BE DONE. 5. PLANTING SOIL MIXTURE FOR BACKFILLING TREES AND SHRUBS OF TREES AND SHRUBS SHALL BE 50% TOP SOIL, 50% COMPOSTED GROUND AND TREE TRUNK SAND, CLAY, CLAY GRAVEL, BRUSH, LEAVES OR OTHER DELETERIOUS MATERIAL AND OF BEAUTIFULLY IMPORT QUALITY. PLANTING SOILS SHOULD NOT BE COMPACTED, BUT SHOULD BE SCARIFIED TO AVOID HEAVING WITH DRYING. ANY PLANT MATERIALS THAT ARE NOT HEALTHY, SOUND, FREE OF DISEASE, PROPERLY ROOTED AND FREE OF INSECTS ARE UTILIZED TO SOIL THE SOIL TO THE CRITICAL REQUIREMENTS OF VARIOUS PLANT SPECIES. 6. ALL PLANTING AREAS SHALL RECEIVE A MINIMUM OF 3" OF SUITABLE ORGANIC MATERIAL (WOOD CHIPS, BARK, MULCH, ETC.) PERCENT TO MAINTAIN SOIL MOISTURE AND INHIBIT WEED GROWTH. 7. ALL TREES AND PLANTS IN THE LAWN AREAS ARE TO RECEIVE A 34" DIAMETER MULCH RING AT THE BASE OF THE TRUNK. ZONE DISTRICT: B5-1A GROSS LAND .188 (ACRE) NET LAND .185 (ACRE) LANDSCAPE OPEN SPACE (IF APPLICABLE) REQUIRED 22 % PROVIDED 212 % STREETSET WIDTH (IF APPLICABLE) REQUIRED 0 PROVIDED 28 LAWN AREA (AS DEFINED IN ORDINANCE) REQUIRED 20 % PROVIDED 20 % TREES PER NET LOT REQUIRED 37 PROVIDED 46 INTEREST TREES REQUIRED 18 PROVIDED 17 TOTAL NUMBER OF TREES REQUIRED 55 PROVIDED 61 SHRUBS (1 SHRUBS PER SQ. TREE 1 SQ. FT. SHRUBS SHALL BE PLANTED IN A CONTINUOUS SYSTEM PER PUNDANT TO BE 30 FADE COUNTY CODE REQUIRED 31 PROVIDED 641 BUSHES (ENLARGED INDUSTRIAL) (1) ZONER REVISIONS: DATE: 9-17-01 DRAWN BY: JL CHECKED BY: MAC JOB NO.: 493-01 PROPOSED PROFESSIONAL OFFICE BUILDING FOR: MR. RAUL MEDINA JR. 8625 NW 72 AVE MIAMI, FL 33166-4600 CABRERA RAMOS ARCHITECTS, INC. 3625 N.W. 82 AVENUE SUITE 214 MIAMI, FLORIDA 33166 (305) 593-0750 FAX (305) 593-8862 MA 0501621 MICHEL A. CABRERA, JR., P.A. Reg. Arch. No. 001316 ROSA E. RAMOS-SOTTA, P.A. Reg. Arch. No. 001038 SHEET NO. L-1 OF TIE PALM TRUNKS DURING TRANSPORTATION. DO NOT TIE PALM TRUNKS AND SET PLUMES AND TREE WITH GRADE 4 LAYERS OF BURLAP TOP AND BOTTOM STEEL BANDING 3" MULCH LAYER COMPACTED SUBGRADE ROOT BALL 8 (3/4"X9") BATTENS TOE NAIL 3/4" BRACE TO BATTENS (4) 3"X4" PRESSURE TREATED WOOD BRACING 3"X4"X4" PRESSURE TREATED WOOD STAKES SOIL MIX PERLITE TABLETS COMPACTED SOIL MIX PALM TREE PLANTING DTL. N.T.S. PLANTING SCHEDULE SYMBOL COMMON NAME BOTANICAL NAME SPECIFICATIONS QUANTITIES NATIVE SPECIES (Y/N) LINDEN LINDEN MUCRON 1 GAL. PILL 10" O.C. 578 NO INDRA INDRA SP 2 GAL. PILL 34" HIGH 30" O.C. 52 NO MINTAS MINTAS LANCEOLATA 2 GAL. PILL 34" HIGH 30" O.C. 44 NO RED-TIP POPLAR CHRYSOBALANUS ICACO 2 GAL. PILL 34" HIGH 30" O.C. 481 YES PACIFIC GRASS CORTADERIA SELLOANA 3 GAL. PILL 34" HIGH 30" O.C. 60 YES SABAL PALMETTO CABBAGE PALM 18" OVERALL HEIGHT 2 YES ROYAL PALM ROystonea ELATA 18" OVERALL HEIGHT 6 YES MAHOGANY SWEETINA HANSONII 18" OVERALL HEIGHT 22 YES LIVE OAK QUERCUS VIRGINIANA 18" OVERALL HEIGHT 16 YES S.J.N. 42nd STREET (BIRD ROAD) LANDSCAPING PLAN SCALE: 1" = 20'-0" 3" MULCH LAYER COMPACTED SUBGRADE SOIL MIX ROOT BALL PERLITE TABLETS COMPACTED SOIL MIX SHRUB PLANTING DTL. N.T.S.
